K2-1107ST-A4DW-06

Identity

• Manufacturer: 韩国韩荣
• Model / MPN: K2-1107ST-A4DW-06
• LCSC: C118141
• Category: tactile-switch
• Description: K2-1107ST-A4DW-06 tactile switch; 3.66.12.5mm; 12V; SPST; rectangular button; 2.5N; vertical SMT; 50mA; 100,000 Cycles
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SMD,6.1x3.6mm
• Pin count: Unknown
• EasyEDA symbol UUID: acbb678e17af4dae89beb0626cae74fb
• EasyEDA footprint UUID: 86ce8dc78e41488ab7709c91b297f285
• EasyEDA device UUID: 6b9cf67d079042e9ae0a611fad0d200a
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 12V
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connector, HMI, and mechanical interface seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/K2-1107ST-A4DW-06/119400.html
• Product URL: https://item.szlcsc.com/datasheet/K2-1107ST-A4DW-06/119400.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category tactile-switch, interfaces gpio, package SMD,6.1x3.6mm, and EasyEDA footprint UUID 86ce8dc78e41488ab7709c91b297f285.
