PAM8302AADCR
Identity
- Manufacturer: DIODES(美台)
- Model / MPN: PAM8302AADCR
- LCSC: C112137
- Category: audio-amplifier
- Description: 2.5W mono Class D audio power amplifier, 2V~5.5V, 1-Channel, 2.5Wx1@4Ω, THD+N:0.3%, Iq:4mA, SNR:80dB, PSRR:50dB, Efficiency:85%
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- Not captured yet.
Package And Footprint
- Package / footprint name: SOP-8
- Pin count: 8
- EasyEDA symbol UUID: 7dce5251e7e9458ab31ed868331512af
- EasyEDA footprint UUID: 114ea734da1646a1859a103ac7dff343
- EasyEDA device UUID: b7be77b252f64902a5e45e9f423e7dbc
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: EasyEDA property: 2V~5.5V.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common HMI, display, audio, touch, and haptic seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/PAM8302AADCR/113369.html
- Product URL: https://item.szlcsc.com/datasheet/PAM8302AADCR/113369.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: audible alerts, speaker outputs, voice prompts, simple playback, and enclosure-mounted sound feedback
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
audio-amplifier, interfaces none captured, packageSOP-8, and EasyEDA footprint UUID114ea734da1646a1859a103ac7dff343.
