74HC4052

Identity

Manufacturer: I-CORE(中微爱芯)
Model / MPN: 74HC4052
LCSC: C111594
Category: analog-mux
Description: Dual 4:1 analog switch, 3V~~9V, Switch Circuit:4:1, 2 channels, Ron:115Ω, Bandwidth:40MHz, tpd:10ns, -40°C~~+85°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

analog: interface
gpio: interface

Package And Footprint

Package / footprint name: SOP-16
Pin count: 16
EasyEDA symbol UUID: fb996c4f0b074c97933287a0d42c5c8b
EasyEDA footprint UUID: e52e644bbb3548988fcc9af5d7d48159
EasyEDA device UUID: a96ff5f8487d4cb4be61f979a9ec7ff3
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 3V~9V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common logic, level-shifting, bus-interface, and analog-switch seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/74HC4052/112821.html
Product URL: https://item.szlcsc.com/datasheet/74HC4052/112821.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: multiplexing analog sensors, ADC inputs, resistor ladders, and configurable measurement paths
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category analog-mux, interfaces analog, gpio, package SOP-16, and EasyEDA footprint UUID e52e644bbb3548988fcc9af5d7d48159.
