LTV-817S-TA1-C

Identity

• Manufacturer: LITEON(光宝)
• Model / MPN: LTV-817S-TA1-C
• LCSC: C109227
• Category: optocoupler
• Description: DC-input phototransistor optocoupler, 1.2V Vf, 50mA output, 5kV isolation, 6V reverse, 35V load, 1 output, 100mV@1mA,20mA VCE(sat).
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SMD-4P
• Pin count: 4
• EasyEDA symbol UUID: 10a394ca03e746b4b2dc1f7919bb8a71
• EasyEDA footprint UUID: 4491e2832ed7468c8e950c01a78106e1
• EasyEDA device UUID: d7b5bbbdba22406e90b025e3954c9610
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/LTV-817S-TA1-C/110448.html
• Product URL: https://item.szlcsc.com/datasheet/LTV-817S-TA1-C/110448.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category optocoupler, interfaces gpio, package SMD-4P, and EasyEDA footprint UUID 4491e2832ed7468c8e950c01a78106e1.
