MCP4728-E/UN

Identity

• Manufacturer: MICROCHIP(美国微芯)
• Model / MPN: MCP4728-E/UN
• LCSC: C108207
• Category: dac
• Description: MCP4728-E/UN 2.7V5.5V I2C Resolution(Bits):12 Number of Channels:4 Interface:I2C Voltage - Supply:2.7V5.5V Voltage - Supply:2.7V5.5V Settling Time:6us Output Type:Voltage Buffer Integral non - linearity:2LSB Integral non - linearity:2LSB Operating Temperature:-40℃+125℃ Operatin
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface

Package And Footprint

• Package / footprint name: MSOP-10
• Pin count: Unknown
• EasyEDA symbol UUID: 86887c3172e8475d803c8ecd8286071e
• EasyEDA footprint UUID: f356325cc63c48a1a283f03f60c5f49f
• EasyEDA device UUID: a84915aa8f1a4491a80697cb00d349bf
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.7V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified second-source/alternate seed for IC categories that only had one option
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/MCP4728-E%252FUN/109426.html
• Product URL: https://item.szlcsc.com/datasheet/MCP4728-E%252FUN/109426.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: analog setpoints, bias generation, sensor simulation, and simple waveform or control voltage outputs
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category dac, interfaces i2c, package MSOP-10, and EasyEDA footprint UUID f356325cc63c48a1a283f03f60c5f49f.
